Technical parameters:
|
Type |
CJX2-F115 |
CJX2-F150 |
CJX2-F185 |
CJX2-F225 |
CJX2-F265 |
CJX2-F330 |
|
|
Rated Current |
Ie max AC-3(Ue≤440V) |
115A |
150A |
185A |
225A |
265A |
330A |
|
Ie max AC-1(θ≤40℃) |
200A |
250A |
275A |
315A |
350A |
400A |
|
|
Main Contacts(NO) |
3、4 |
3、4 |
3、4 |
3、4 |
2、3、4 |
2、3、4 |
|
|
Rated Insulated Voltage(Ui) |
1000V |
1000V |
1000V |
1000V |
1000V |
1000V |
|
|
Rated Impulse Withstand Voltage |
8kV |
8kV |
8kV |
8kV |
8kV |
8kV |
|
|
Rated Operational Voltage (Ue)max |
1000V |
1000V |
1000V |
1000V |
1000V |
1000V |
|
|
Standards-compliant |
IEC60947-4-1, GB14048.4, EN60947-4-1 |
|
|||||
|
Conventional Thermal Current Ith(θ≤40℃) |
200A |
250A |
275A |
315A |
350A |
400A |
|
|
Operation Frequency(times/h) |
AC-1，AC-2，AC-3 |
1200 |
1200 |
1200 |
1200 |
1200 |
600 |
|
AC-4 |
300 |
300 |
300 |
300 |
300 |
300 |
|
|
Rated Power(AC-3) |
220/240V |
30kW |
40kW |
55kW |
63kW |
75kW |
100kW |
|
380/400V |
55kW |
75kW |
90kW |
110kW |
132kW |
160kW |
|
|
415V |
59kW |
80kW |
100kW |
110kW |
140kW |
180kW |
|
|
440V |
59kW |
80kW |
100kW |
110kW |
140kW |
200kW |
|
|
500V |
75kW |
90kW |
110kW |
129kW |
160kW |
200kW |
|
|
660/690V |
80kW |
100kW |
110kW |
129kW |
160kW |
220kW |
|
|
1000V |
65kW |
65kW |
100kW |
100kW |
147kW |
160kW |
|
|
Connection/Wiring
Operation Voltage (θ≤55℃） |
Number of Lines Line Size(mm2) |
2 20×3 |
2 25×3 |
2 25×3 |
2 32×3 |
2 32×4 |
2 30×5 |
|
Cable with Splicing(mm2) |
95 |
120 |
150 |
185 |
240 |
240 |
|
|
Cable with Connector(mm2) |
95 |
120 |
150 |
185 |
240 |
- |
|
|
Screw Diameter |
Φ6 |
Φ8 |
Φ8 |
Φ10 |
Φ10 |
Φ10 |
|
|
Tightening Torque(N.m) |
10 |
18 |
18 |
35 |
35 |
35 |
|
|
Equipped With Fuse Protector (SCPD) |
Type |
RT16-2 250A |
RT16-2 355A |
RT16-3 425A |
RT16-3 500A |
RT16-3 630A |
RT16-3 800A |
Dimensions(mm):
CJX2-F115/1154-330/3304
|
CJX2-F |
a |
p |
Q |
1 |
s |
φ |
f |
b |
b1 |
M |
N |
C |
L |
G |
H |
φ1 |
G1 |
Z |
Y |
x1 |
|
|
500V≤ |
>500V |
||||||||||||||||||||
|
115 |
163.5 |
37 |
29.5 |
60 |
15 |
M6 |
131 |
162 |
137 |
147 |
124 |
171 |
107 |
80 |
120-106 |
6.5 |
106 |
13.5 |
44 |
10 |
15 |
|
1154 |
200.5 |
37 |
29.5 |
60 |
15 |
M6 |
131 |
162 |
137 |
147 |
124 |
171 |
107 |
80 |
120-106 |
6.5 |
143 |
13.5 |
44 |
10 |
15 |
|
150 |
163.5 |
40 |
26 |
57.5 |
20 |
M8 |
131 |
170 |
137 |
150 |
124 |
171 |
107 |
80 |
120-106 |
6.5 |
106 |
13.5 |
44 |
10 |
15 |
|
1504 |
200.5 |
40 |
25 |
55.5 |
20 |
M8 |
131 |
170 |
137 |
150 |
124 |
171 |
107 |
80 |
120-106 |
6.5 |
143 |
13.5 |
44 |
10 |
15 |
|
185 |
168.5 |
40 |
29 |
59.5 |
20 |
M8 |
130 |
174 |
137 |
154 |
127 |
181 |
113.5 |
80 |
120-106 |
6.5 |
111 |
13.5 |
44 |
10 |
15 |
|
1854 |
208.5 |
40 |
29 |
59.5 |
20 |
M8 |
130 |
174 |
137 |
154 |
127 |
181 |
113.5 |
80 |
120-106 |
6.5 |
151 |
13.5 |
44 |
10 |
15 |
|
225 |
168.5 |
48 |
21 |
51.5 |
25 |
M10 |
130 |
197 |
137 |
172 |
127 |
181 |
113.5 |
80 |
120-106 |
6.5 |
111 |
13.5 |
44 |
10 |
15 |
|
2254 |
208.5 |
48 |
17 |
47.5 |
25 |
M10 |
130 |
197 |
137 |
172 |
127 |
181 |
113.5 |
80 |
120-106 |
6.5 |
151 |
20.5 |
44 |
10 |
15 |
|
265 |
201.5 |
48 |
39 |
66.5 |
25 |
M10 |
147 |
203 |
145 |
178 |
147 |
213 |
141 |
96 |
120-106 |
6.5 |
140 |
20.5 |
38 |
10 |
15 |
|
2654 |
244.5 |
48 |
34 |
66.5 |
25 |
M10 |
147 |
203 |
145 |
178 |
147 |
213 |
141 |
96 |
120-106 |
6.5 |
186 |
20.5 |
38 |
10 |
15 |
|
330 |
213 |
48 |
43 |
74 |
25 |
M10 |
147 |
206 |
145 |
181 |
158 |
219 |
145 |
96 |
120-106 |
6.5 |
154.5 |
20.5 |
38 |
10 |
15 |
|
3304 |
261 |
48 |
43 |
74 |
25 |
M10 |
147 |
206 |
145 |
181 |
158 |
219 |
145 |
96 |
120-106 |
6.5 |
202.5 |
20.5 |
38 |
10 |
15 |
