● Below 2000 meters above sea level;
● Ambient medium temperature should be within -5 ℃ to +40 ℃ (+45 ℃ for marineproducts);
● lt can withstand the effect of damp air;
● lt can withstand the effect of salt fog or oil mist;
● lt can withstand the effect of moulds;
● lt can withstand the effect of nuclear radiation;
● The max inclination is 22.5 degree;
● lt still can work reliably when the ship subjects to normal vibration;
● lt can still work reliably if the product subjects to the earthquake (4g).
● Places where the surrounding medium is free from explosion danger, and far awayfrom gas or conductive dust that would erode the metal or destroy the insulation;
● Keep away from rain or snow.
Product selection guide：
Main performance indexes：
|
Type |
AOME-800 |
AOME-1000 |
AOME-1250 |
|||
|
Pole |
3P,4P |
3P,4P |
3P,4P |
|||
|
Rated current (A) |
500-800 |
630-1000 |
850-1250 |
|||
|
Rated voltage |
AC400V |
AC400V |
AC400V |
|||
|
Rated insulation voltage |
AC1000V |
AC1000V |
AC1000V |
|||
|
Short-circuit breaking capacity
(KA)Icu/Ics
|
AC 400V |
65/50 |
65/50 |
65/50 |
||
|
Operating cycle number |
ON |
1000 |
1000 |
1000 |
||
|
OFF |
4000 |
4000 |
4000 |
|||
|
Outline dim. (mm) a-b-c-ca |
3P |
210-257-103-155 |
210-257-103-155 |
210-257-103-155 |
||
|
4P |
280-257-103-155 |
280-257-103-155 |
280-257-103-155 |
|||
|
Weight (kg) |
3P |
5.7 |
5.7 |
5.7 |
||
|
4P |
7.5 |
7.5 |
7.5 |
|||
|
Electric operating device (MD) |
● |
● |
● |
|||
|
External driving operating handle |
● |
● |
● |
|||
|
Automatic release |
Electronic type |
Electronic type |
Electronic type |
|||
