Technical parameters:
|
TYPE |
CJX2-115 |
CJX2-150 |
CJX2-170 |
||
|
Rated Power kW/HP(AC-3) IEC60947-4-1 GB14048.4 |
200-240V |
30/40 |
40/50 |
55/75 |
|
|
380-440V |
55/75 |
75/100 |
90/125 |
||
|
500-550V |
75/100 |
90/125 |
110/145 |
||
|
Rated Current A(AC-3) IEC60947-4-1 GB14048.4 |
200-240V |
125 |
165 |
175 |
|
|
380-440V |
115 |
150 |
170 |
||
|
500-550V |
200 |
250 |
250 |
||
|
Conventional Thermal Current Ith:(A) |
200 |
250 |
250 |
||
|
Rated Insulated Voltage Ui:(V) |
1000 |
||||
|
Auxiliary Contact
AC-15 |
Contact Arrangement |
Standard |
--- |
||
|
Special |
--- |
||||
|
Rated Current A(AC-15) IEC60947-5-1 GB14048.5 |
200-240V |
--- |
|||
|
380-440V |
--- |
||||
|
Conventional Thermal Current Ith:(A) |
--- |
||||
|
Electric Life(Million Times) |
0.8 |
||||
|
Mechanical Life(Million Times) |
5 |
||||
External Dimensions(mm) H(height):
